MD41 Development Kit

Powered by LM10 Beamforming

A New Era For 3D Sensing

MD41 Key Features

Introducing the MD41 Development Kit. This new kit is based on the Open Development Platform (ODP), allowing you to quickly create a custom Lidar platform in 3-6 months. They are based on our Modular Hardware platform and Modular Software stack, making it easy to utilize via our API’s.

Learn more


MD41 Development Kit

Range

80 meters maximum range;
50 meters outdoors

Field of View

100° x 31° FoV

Resolution

0.5° x 0.5°

Frame Rate

20 Hz

Software Defined

Not supported by receiver, as Receiver is Scan only type.

System Interface

MIPI/USB3.0

Host Processing

PC with Ubuntu Linux

Software & Tools

ROS-based Rviz, REST API & Data Stream API, Python, C++

Included in Development Kit

MD41 System fully functional with Software for Host Compute

Power Adapter

Type-C USB Cable for Host Computer

System bring up support

Software Runtime License for Evaluation, Prototype, and Demo

Dimensions

10.5 x 6.5 x 8.5 cm

Order Information



 MD41 Development Kit

SKU: MD41-DK

 MD41 Sensor Head only

SKU: MD41

Key Advantages of the MD41 Development Kit

Out-of-the-Box
Developers want to quickly set up the tools and hardware to evaluate and learn about the new MD 41. The Development Kit includes software, cables, and power supply to simplify this process, allowing developers to focus on their applications.

Evaluation
For key performance indicators (KPIs) such as resolution, point cloud quality, multipath performance, and ROI capabilities.

Prototyping
The next step a Lidar System user or developer will want to take is to integrate MD41 into a potential application or use case and create a proof of concept to validate the system’s functionality and provide an early demo.

Demonstration
Finally, to demonstrate applications utilizing the ROS framework or an internal framework via integration with APIs.

The MD41 is specifically designed for a wide range of applications. Its high-performance features, seamless manufacturability, and lightweight build, and exceptional reliability due to an all-chip design make these systems highly suitable for robotics, surveillance, forklifts, and automotive L2+/ADAS. They are well-suited for ensuring safety and navigation in environments such as autonomous mobile robots (AMRs) and drones.

Next Generation Hardware, Defined By Software

Ideal industries for MD41 Development Kit

Lumotive products scale across multiple industries and offer a wide range of applications

Talk to an expert
